CNPC JICHAI 190 SERIES DIESEL ENGINE MODEL-C8190ZLC Cylinder Head Assy.511.03H.00A
Jichai C8190ZLC Marine diesel engine spare parts
| 1 | Cylinder Head Assy. | 511.03H.00A |
| 2 | Cylinder Head Gsket. | 206L.01.31 |
| 3 | Seal Gasket | 12VB.01.146 |
| 4 | Throttle Valve | 12VB.01.141 |
| 5 | Sleeve | 12VB.01.05 |
| 6 | Seal ring | 12V.01.05 |
| 7 | Connecting Water Pipe | 12V.01.09 |
| 8 | Cylinder Liner | 511.01.51A |
| 9 | Upper Seal Ring | 511.01.61 |
| 10 | Seal Ring | 12VB.01.136 |
| 11 | Seal Ring | 12V.01.14 |
| 12 | Piston | 206L.05.01 |
| 13 | Piston Pin | 12V.05.08A |
| 14 | Compression ring(Top) | 12VB.05.09B |
| 15 | Compression ring | 12VB.05.11 |
| 16 | Oil ring Subassembly. | 12VB.05.20 |
| 17 | Small end bushing | 12VB.05.10.08A |
| 18 | Lower Connecting rod bearing | 12VB.05.10.05A |
| 19 | Lower Connecting rod bearing | 12VB.05.10.04A |
| 20 | Seat Ring(upper cover cylinder Head) | 12VB.03.11 |
| 21 | Oil Seal Sub Assy.free end | 511.01.70A |
| 22 | Oil Seal Sub Assy.fly wheel end | 511.01.60 |
| 23 | Gear Ring | 206L.44.02 |
| 24 | Intake Manifold Gasket | 12VB.08.10.14 |
| 25 | Inter Cooler Inlet Chamber Gasket | 208L.08.07 |
| 26 | Heat Shield | 208L.09.90B |
| 27 | Fuel Filter Assy. | 12VB.10.00 |
| 28 | FeedPump Assy. | 206L.11P.00 |
| 29 | Injection Pump Assy. | 208L.12P.00 |
| 30 | Injector Assy. | 12VB.16.00E |
| 31 | Nozzle assembly Sub assy. | 12V.16.20E |
| 32 | Nozzle cap nut | 12V.16.14 |
| 33 | Nozzle cap nut washer | 12V.16.15 |
| 34 | Injection Pump Transmission | 264L.15P.00 |
| 35 | Fuel Pipe Sub Assy. | 208L.14.40.20 |
| 36 | Fuel Return Pipe Sub Assy. | 208L.14.80 |
| 37 | Fuel Return Pipe | 12VB.14.50.10 |
| 38 | Fuel Return Pipe | 12VB.14.50.20 |
| 39 | Fuel Pipe Sub Assy. | 208L.14.40.10 |
| 40 | Fuel return Pipe | 12VB.14.30.10B |
| 41 | Fuel return Pipe stop valve | 208L.14.20 |
| 42 | Bleeding Pipe Fuel Filter | 206L.14.30 |
| 43 | Fuel out let pipe Fuel filter | 208L.14.90 |
| 44 | Fuel in let pipe Fuel filter | 208L.14.50 |
| 45 | Solenoid Operated Valve | 266L.14.140 |
| 46 | Fuel inlet pipe injection pump | 208L.14.60 |
| 47 | Fuel inlet pipe supply pump | 208L.14.110 |
| 48 | Fuel Out let pipe supply pump | 208L.14.120 |
| 49 | Fuel injection Pipe | 208L.14.10 |
| 50 | Fuel return Pipe | 208L.14.130 |
| 51 | Oil Pump Assy. | 208L.17.00 |
| 52 | Oil Filter Assy. | 208L.18.00 |
| 53 | Centrifugal Filter Assy. | 206L.19.00 |
| 54 | Oil Cooler Assy. | 208L.21.00A |
| 55 | Water Pump Assy. | 208L.22.00 |
| 56 | Sea Water Pump Assy. | 208L.22H2.00 |
| 57 | Turbo Charger Assy. | 208L.26.00 |
| 58 | Inter Cooler Assy. | 208L.27.00 |
| 59 | Hand Priming Oil Pump Assy. | 12V.29.00 |
| 60 | Air Filter Assy. | 208L.36.00 |
| 61 | Fresh Water Cooler Assy. | 208L.38.00 |
| 62 | Special Tools | 208L.42.00 |
