Coupling Assembly LC3410 208L.44.00 for JDEC 8190ZLCD connecting the engine to the generator

Jichai Z8190ZLC-1 Engine Technical Specifications

Manufacturer: Jinan Diesel Engine Co., Ltd. (Jichai)

Engine Model: Z8190ZLC-1

Maximum Engine Power: 640 kW

Rated Speed: 1500 r/min

Number of Cylinders: 8

Displacement: 47.6 L

Bore × Stroke: 190 × 210 mm

Compression Ratio: 14:1

Cycle: 4-Stroke

Fuel System: Direct Injection

Governor System: Electronic Governor

Cooling System: Water-Cooled

Starting System: 24V DC

Air Intake System: Turbocharged & Intercooled

Fuel Consumption Rate: ≤218 g/kWh

Lubricating Oil Consumption: ≤1.2 g/kWh

Total Engine Oil Capacity: 170 L

Oil Sump Capacity: 160 L

Oil Pressure at Rated Speed: 392–784 kPa

Exhaust Gas Temperature: ≤510°C

Exhaust Gas Flow: 95.2 m³/min

Gas Consumption: 54.6 m³/min

Air Flow: 320 m³/min

Maximum Allowable Intake Pressure: 6.23 kPa

Total Coolant Capacity: 84 L

Thermostat Opening Temperature: 82–93°C

Maximum Coolant Temperature: 104°C
